Syrup Production Line

Syrup Production Line SD-QGF

Description of Syrup Production Line:
The SD-QGF-140 syrup production line is a kind of filling and lid-revolving machine composed of bottle-setting machine, wind-blowing equipment, eight-head filling machinery and loid-revolving machine.
This machine can also conect with other machine to form a whole line, such as auto-label-attaching machine, box-sealing equipment and so on.
It can be equipped with 6,8,10 straight-line-filling heads with the GMP standar.
It is the most ideal one of produce syrup and nutrition liquid equipments at present.

Characteristics of Syrup Production Line:
1. For the bottle-blowing machine, it can be dust-absorbing and dust-collecting free. So it doesn's pollute the environment , and can blow the bottle clean .
2. The filling and lid-revolving heads can use as you need for producing requirement of different output .
3. The part which touches the medicine liquid is made of 316L stainless steel completely, meeting the requirement of GMP.
4. Regarding the lid-revolving, it is using the style of magnetic force ,so it doesn's hurt the lid ,and the lid will not lose .
5. PLC controled , it can be operated alone and can also be connected to operated.

Technical Parameters of SD-QGF Series Syrup Production Line :
Producing capacity 30-120 bottle/min
Diameter of the bottle φ 30-120mm
Filling capacity 60-300ml
Power 2.8kw .380V 50HZ

Shanghai Ouda Packing Machinery & Material Co., Ltd is a professional manufacturer of syrup production line in China. Apart from syrup production line, we still provide dairy filling machine, oil filling machine, automatic monoblock filler capper, linear filling machine, etc. And our products have been quite popular among customers from Syria, Libya, Iraq, Egypt, Pakistan, Jordan, Turkey, Iran, Italy, Britain, the United States, Indonesia, Malaysia, Algeria, Sudan, Tanzania, Russia, Saudi Arabia, and so on. If you need our syrup filling machine, please don't hesitate to contact us.
