Home » Products » Teabag Packing Machine

Teabag Packing Machine

SD-DPC-1 Teabag Packing Machine
1. Description:
This SD-DPC-1 teabag packing machine can seal from different 3 sides, and automatic dosing is also available.

2. Technical Parameters:

Sealing mold 3-side sealing
Filling amount 5-40ml
Packing speed 50-100bags/min
Bag size L: 55-110mm, W: 30-80mm
Power 220V 50HZ 1.5KW
Weight 350kg
Dimension 600×790×1800mm
SD-DPC-6 Teabag Packing Machine
1. Description:
This SD-DPC-6 teabag packing machine can automatically finish the work of dosing and sealing by cotton strings. And the teabags can be sealed from different 3 sides.

2. Technical Parameters:

Sealing mold  3-side sealing
Filling amount  5-40ml
Packing speed  50-100bags/min
Bag size  L: 55-110mm, W: 30-80mm
Power  220V 50HZ 1.5KW
Weight  350KG
SD-DPC-8 Teabag Packing Machine
1. Description:
This SD-DPC-8 teabag packing machine can automatically finish the operation of dosing, heat sealing and labeling.

2. Technical Parameters:

Output  40-50bags/minute
Max. dosage  8cm3Bag
Dimensions  62.5mm×50mm
Tag dimensions  28mm×24mm
Thread length  210mm
Power Supply  AV380, 0.75KW
Weight  565KG
SD-DPC-A Teabag Packing Machine
1. Description:
This SD-DPC-A teabag packing machine can automatically do the work of dosing, cold sealing, and labeling. And its packaging is two-side in longitudinal direction.

2. Technical Parameters:

Output 105±5bags/minute
Max. dosage 15cm3
Bag dimensions 50×62.5mm
Envelope dimensions 70×65mm
Tag dimensions 28×24mm
Thread length 210mm
Power supply AC 380V / 220V
Total power 1.25kW
Weight 540kg
Overall dimensions 1700×900×2000mm
SD-DPC-03 Teabag Packing Machine
1. Description:
This SD-DPC-03 teabag packing machine is mainly used for the automatic packaging of teabags of vegetable seed, Chinese herbal medicine, and health tea. It can finish the work of bag making, metering, filling, cutting, sealing, code printing, counting, and finished products outputing.

2. Technical Parameters:

Metering range 5-40ml
Bag dimensions (inner bag) Lenght: 60-100mm; width: 47-72.5mm
(outer bag) Lenght:75-125mm; width: 110-180 mm
Packing speed 30-50bags/min
Total power 220V, 50HZ, 2.9KW
Total weight 650kg
Overall dimensions 1050×910×2005mm
SD-DXDC15 Teabag Packing Machine
1. Description:
This SD-DXDC15 teabag packing machine can automatically finish the work of illing, heat sealing, threading, labeling, over-wrapping and automatic sealing. Its loading system is adjustable so as to fill teabags in different dimensions. And its packing materials are mainly paper/PE, plastics/foil/PE and plastics/PE.

2. Technical Parameters:

Output 105±5bags/minute
Max. dosage 15cm3
Bag dimensions 65×62.5mm
Envelope dimensions 82×75mm
Tag dimensions 28×24mm
Thread length 210mm
Power supply AC 380V / 220V
Total power 2.36kW
Weight 1210kg
Overall dimensions 1.688×1.33×2.205m
Packing 25pcs/carton
Carton dimensions 1.84×1.29×1.89m

Shanghai Ouda Packing Machinery & Material Co., Ltd is a professional manufacturer of teabag packing machine in China. Apart from teabag packing machine, we still provide pillow packing machine, bread packing machine, candy packing machine, etc. And our products have been quite popular among customers from Syria, Libya, Iraq, Egypt, Pakistan, Jordan, Turkey, Iran, Italy, Britain, the United States, Indonesia, Malaysia, Algeria, Sudan, Tanzania, Russia, Saudi Arabia, and so on. If you need our tea bag packaging equipment, please don't hesitate to contact us.
